Description
Type :Ball Joint Rod End Bearing
Bore Size :5 - 50 mm
housing Material:45# high carton steel
Surface :Zinc plated or Nickle plated
Rod Thread :Left or right hand thread
Model Number :
Ball Material :Bearing Steel / Gcr15
Color :Copper,Silver
Diameter Size :20mm
Remark: for left thread ball joint rod end bearing, please add suffix "L", e.g. "PHSL8"
for stainness steel material ball joint rod end bearing, please add "SS", e.g."PHS8SS"
Packaging Details：Colour Boxes+Carton+Pallet Packing: Standard packing for rod end bearing
also can according to customers requirement
Port ：Shanghai/Ningbo
Delivery time :Samples 3-5 days, small order 7-10days,big order 10-20days.
OTHERS
1. Material of ball joint rod end bearing body are carbon steel 45#
Material of inner ball are Gcr15 bearing steel
Liner: brass or bronze
2. Normally, ball joint rod end bearing are available with left or right-hand, female or male threads.
3.Ball joint rod end bearing from WERB have the sliding contact surface combinations steel-on-steel, steel-on-bronze, steel-on-PTFE composite material, and steel-on-PTFE fabric. Usually, the material of the internal ball is bearing steel, which performance are much superior.
4.Some ball joint rod end bearing types require lubrication, and other types are maintenance free.
5.Besides, zinc/chrome/nickel/multicolour can be plated
Bore Size :5 - 50 mm
housing Material:45# high carton steel
Surface :Zinc plated or Nickle plated
Rod Thread :Left or right hand thread
Model Number :
Ball Material :Bearing Steel / Gcr15
Color :Copper,Silver
Diameter Size :20mm
Remark: for left thread ball joint rod end bearing, please add suffix "L", e.g. "PHSL8"
for stainness steel material ball joint rod end bearing, please add "SS", e.g."PHS8SS"
Packaging Details：Colour Boxes+Carton+Pallet Packing: Standard packing for rod end bearing
also can according to customers requirement
Port ：Shanghai/Ningbo
Delivery time :Samples 3-5 days, small order 7-10days,big order 10-20days.
OTHERS
1. Material of ball joint rod end bearing body are carbon steel 45#
Material of inner ball are Gcr15 bearing steel
Liner: brass or bronze
2. Normally, ball joint rod end bearing are available with left or right-hand, female or male threads.
3.Ball joint rod end bearing from WERB have the sliding contact surface combinations steel-on-steel, steel-on-bronze, steel-on-PTFE composite material, and steel-on-PTFE fabric. Usually, the material of the internal ball is bearing steel, which performance are much superior.
4.Some ball joint rod end bearing types require lubrication, and other types are maintenance free.
5.Besides, zinc/chrome/nickel/multicolour can be plated
6.Stainless steel ball joint rod end bearing also available
